Reference 2
High End Floorstanding speaker
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 630 watts
- 35 x 116 x 53 cm (W x H x D)
Item no.: 04397
35 x 116 x 53 cm (W x H x D) including base construction
630 watt music load capacity
62 kilogram
Iconic sound for the highest quality demands
Chassis with new BCT diaphragm (Black Ceramic Tungsten)
Sweeping cabinet shape for unlimited music pleasure
WBT terminals for optimal signal connection
Acoustically neutral cover with magnetic attachment
10 years warranty on Reference passive loudspeakers
PURE AESTHETICS
The new Reference 2
As an imposing 3-way floorstanding loudspeaker, the Reference 2 has the potential to provide exceptional and uncompromising listening pleasure even in very large rooms. With the advantages of smaller proportions compared to the flagship of the series, they are perfect for reference level stereo reproduction and are also an excellent choice for home theater applications.
Visually and technically innovative
The cabinets of the Canton Reference 2 are designed according to the latest acoustic findings free of edges. Their elegant form follows function, resulting in a speaker with remarkable characteristics: in addition to its modern design, it is also extremely stable and provides a perfect basis for sound-optimized radiation. The workmanship of the cabinets is of the highest quality and allows for aesthetic integration in any living environment. Four speaker drivers operate in a 3-chamber system, offering perfectly sized volumes for each branch of the 3-way speaker design. The double-bass configuration with 219 mm woofers, in conjunction with the optimized dispersion ratio of the latest generation bass guide, ensures enormous low bass, while also allowing flexible placement of the Reference 2 in the listening room. The 174 mm midrange driver, which is deliberately positioned at the top of the speaker, ensures authentic, lively reproduction of voices. Visually and acoustically the ideal complement is the powerful BC tweeter with 25 mm dome tweeter made of black aluminum oxide ceramic.
Sound optimized
The Reference 2 loudspeakers integrate all drivers flush into the round baffle with the aid of the new three-dimensional ASW (Asymetric Waveguide Ring) cover rings made of polyoxymethylene (POM). These optimize the dispersion characteristics in the high-frequency and midrange ranges. The enclosure design is focused on sound optimization and uses strong multi-layer laminate and sophisticated damping and internal stiffening for low-resonance enclosures. The new crossovers with epoxy resin-glass fabric composite and a copper overlay of 70 µm allows for large dim-ionized conductor cross sections. The arrangement of components on the crossover minimizes magnetic field interference. This precise design and the use of high-quality components ensure optimum performance and precise sound.
Contact
The Reference 2 speakers are equipped with WBT's low-mass nextgen™ binding posts and high-quality gold-plated copper bridges, enabling single, bi-wiring and bi-amping operation. Thanks to their significantly lower mass compared to conventional binding posts, eddy currents are reduced, resulting in a superior sound image. The terminal plate of the Reference 2 speaker terminal has been extended by a level adjustment (Room Compensation). This allows the sound pressure levels of the midrange and tweeter to be precisely raised or lowered in 1.5 decibel steps, optimising the speakers for a variety of listening room characteristics and listening positions.
Processing and surfaces
The Reference 2 speakers are manufactured with the utmost care and precision in Germany, at the company headquarters in Weilrod. Thanks to the use of first-class materials and components, consistent and precise quality is guaranteed. The Reference 2 is available in three exquisitely designed finishes that underscore the high standards of the Reference series. The high-quality walnut veneer is refined using a special sanding technique and matte lacquer treatment, resulting in a captivating, fine-pored surface.
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 820 watts
- 39 x 133 x 63 cm (W x H x D)
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 500 watts
- 325 x 109 x 49 cm (W x H x D)
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 370 watts
- 30 x 101 x 46 cm (W x H x D)
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 320 watts
- 28 x 98 x 43 cm (W x H x D)
- 2-way bass reflex system
- Black Ceramic tungsten technology
- 220 watts
- 26 x 45 x 39 cm (W x H x D)
- 3-way bass reflex system
- Black Ceramic tungsten technology
- 230 watts
- 70 x 27 x 39 cm (W x H x D)
- Bass reflex with passive diaphragm
- 12" Black Ceramic tungsten technology
- 750 watts
- 49 x 59 x 53 cm (W x H x D)
Dealer search
Experience the Reference Live at one of the following dealers:
Triangle Trading Enterprise Irina Khojainova-Blättermann
12203 Berlin
MD Sound Electronic GmbH Martin Dittmeier
97783 Karsbach-Weyersfeld
Reference 2 Technical specifications
Reference 2
Item no.: 04397
Shipping:
Pallet
Warranty period:
10 years
weight:
62 kg
Dimensions (WxHxD):
35 x 116 x 53 (B x H x T mit Sockel) cm
Acoustic principle:
3-way Bass reflex system
Principle passive resonator:
Bass reflex
Radiation direction resonator:
Downfire
Tweeter quantity:
1
Tweeter size:
25 mm
Tweeter material:
Aluminum ceramic oxyd
Midrange driver quantity:
1
Midrange driver size:
174
mm
Midrange driver material:
Black ceramic tungsten (Wave surround)
Woofer quantity:
2
woofer size:
219
mm
woofer material:
Black ceramic tungsten
Nominal load capacity:
370
watts
Music load capacity:
630
watts
Transmission range:
19...40.000
Hz
Crossover frequencies:
160 / 3.000
Hz
Impedance:
4...8
ohm
Level adjustment
:
yes
Extended data
Efficiency 2.83V/1m:
88
db
Connections:
WBT-Connector terminal with level adjustment
Dolby Atmos licensed:
no
Woofer Wave surround:
yes
Midrange Wave Bead:
yes
Front cover material:
fabric
Level adjustment tweeter:
yes
Double Cone:
yes
Transmission Front Plate:
yes
DC switch technology:
yes
Bass Guide:
yes
Unit socket included:
yes
Size supplement (WxDxH):
4x4x12 cm
Unit feet:
yes
Height-adjustable unit feet:
yes
Preparation spikes:
yes
Preparation absorber:
no
Bi-Wiring / Amping Terminal:
yes
Cabinet material:
Multilayer laminate
Cabinet surface:
Piano Finish
Extended special features
Terminal contact material:
golden
Easy Link Terminals:
no
Coaxial loudspeaker:
no
TCC:
yes
Mounting type front cover:
magnetic
Terminal banana plug suitable:
yes
Room adjustment:
yes
Preparation for wall mounting:
no
Wall mounting possible:
no
Suitable for ceiling mounting:
no
Moisture-protected:
no
