Output power:
100 W per channel into 8 Ω / 200 W per channel into 4 Ω (THD 0.08 %, two channels driven)
Amplifier technology:
Class D with PFFB technology (Post-Filter Feedback)
THD+N:
≤ 0.005 % (-106 dB, A-weighted)
Signal-to-noise ratio (SNR):
≥ 120 dB
Damping factor:
94
Frequency response:
20 Hz - 20 kHz (± 0.5 dB)
Impedance range:
2 - 8 Ω
Audio components:
ESS ES9039Q2M high-performance DAC, two TI TPA3255 amplifiers, six TI OPA1612 operational amplifiers
Analog input (ADC):
Up to 192 kHz / 24 bit
Bit-perfect playback:
Up to 192 kHz / 24 bit
Dynamic range:
≥ 120 dB
Connectivity:
Wi-Fi 6E, Bluetooth 5.3 (two-way), Ethernet
Streaming:
WiiM streaming platform, Spotify Connect, TIDAL Connect, Qobuz Connect, Google Cast Audio, Roon Ready, DLNA
Voice control:
Amazon Alexa, Google Assistant
Multiroom:
Grouping with WiiM, Echo and Nest devices, Alexa multi-room with UHD
EQ and room correction:
Input-specific EQ, 10-band graphic and parametric EQ, 24 EQ presets, RoomFit™ room correction
External USB storage:
Usable as media library and media server, supports FAT32, NTFS and EXT4
Control:
3.5-inch touchscreen, multifunctional rotary knob, WiiM Home app, WiiM Voice Remote 2
Power supply:
100-240 V, 50/60 Hz AC
